Nokia
FQFA
What it does: Integrated WCDMA base station. Interfaces and data rates: Iub via IP/Ethernet; TRS 100/1000BASE-T with P+E; SFP 1000BASE-X; LMP 1000BASE-T; SYNC; EAC: 6 inputs + 2 switchable inputs/output.
1 part number: 472751A
Viewing: model overview
Request a QuoteRequest current availability, condition and pricing. Delivery terms are agreed in the quotation.
Main specifications
SynchronizationIEEE 1588v2; SyncE (ITU-T G.8261; excluding electrical SFP); via HDMI SYNC: external GPS-receiver or clock signal 2.048 MHz
ModulesIntegrated RF, baseband, clocking and control, external interfaces and transport; optional antenna FAFQ (473019A)
Interfaces and data ratesIub via IP/Ethernet; TRS 100/1000BASE-T with P+E; SFP 1000BASE-X; LMP 1000BASE-T; SYNC; EAC: 6 inputs + 2 switchable inputs/output
Interfaces / connectors2 × N-female (ANT-1/2); 2 × RJ45 (TRS, LMP); 1 × SFP; 2 × HDMI (SYNC, EAC); 3-screw-type connector AC; grounding M5/M8
Additional technical information
- Family
- PN 472751A; Flexi Lite
For PN 472751A. - Weight
- PN 472751A; ≈12.5 kg, standalone BTS
For PN 472751A. - IP rating
- PN 472751A; IP65
For PN 472751A. - Technologies
- PN 472751A; WCDMA/HSPA (RU50EP1)
For PN 472751A. - Power supply
- PN 472751A; 100–240 V AC, 50/60 Hz
For PN 472751A. - Dimensions
- PN 472751A; 380 × 326 × 101 mm
For PN 472751A. - Installation environment
- PN 472751A; Indoor/outdoor; wall, mast, lighting pole, billboard, cabinet, utility room
For PN 472751A. - Operating RF bands / ranges
- PN 472751A; B2 (PCS)
For PN 472751A. - Uplink frequency
- PN 472751A; 1850–1910 MHz
For PN 472751A. - Downlink frequency
- PN 472751A; 1930–1990 MHz
For PN 472751A. - TX / RX modes
- PN 472751A; 2T2R
For PN 472751A. - RF output power
- PN 472751A; 2 × 0.25…5 W; step 1 dB
For PN 472751A. - Bandwidth
- PN 472751A; TX 20+20 MHz; RX 40 MHz (full-band sliding window, sector-independent); WCDMA-channel 5 MHz
For PN 472751A. - Capacity
- PN 472751A; HSPA up to 84 Mbit/s; configurations 1 omni, 1+1, 2+2, MIMO 1/2 omni
For PN 472751A. - Chassis
- PN 472751A; Standalone monoblock, ≈12.5 L, active cooling
For PN 472751A. - Functional role
- PN 472751A; Micro-/pico-cell coverage and capacity WCDMA
For PN 472751A. - Architecture
- PN 472751A; All-in-one BTS platform-based Flexi Multiradio
For PN 472751A. - Subtype
- PN 472751A; Compact WCDMA BTS 1900 MHz
For PN 472751A. - Details
- PN 472751A; −35…+55 °C; sensitivity of a single receive branch −107…−121 dBm; two-branch diversity
For PN 472751A. - Installation conditions
- Wall; pole, kit FMQB (472469A)
- Connection notes
- RNC via Iub; antenna FAFQ (473019A) or external antenna
