ABIL

Name: Nokia ABIL
Brand: Nokia

What it does: Baseband processing. Technologies: NR.

3 part numbers: 474020A / 474020B / 474020A; 474020B

Viewing: model overview

Request a Quote

Request current availability, condition and pricing. Delivery terms are agreed in the quotation.

Main specifications

FamilyAirScale

TechnologiesNR

Capacity5G, SRAN20A: 4 cells 5/10/15/20 MHz 2T2R/4T4R or 1 cell 100 MHz 32T32R (8 × 4); hardware limit DL 7 Gbit/s, UL 3.5 Gbit/s; available capacity depends on software and feature set

SynchronizationIncluded AirScale SM: centralized synchronization from common unit

ChassisAMIA; AMOB; AMOD

Modules2 pluggable optical transceivers SFP28 and 2 QSFP28

Functional rolePer-channel processing baseband and optical interfaces to radio units

Interfaces and data ratesS-RF1/S-RF2: CPRI 9.83, eCPRI 10.31/25.78 Gbit/s; Q-RF1: CPRI 9.83, eCPRI 10.31 Gbit/s; Q-RF2: CPRI 9.83, eCPRI 10.31/25.78 Gbit/s; IQC CPRI for FDD; mixing of types not supported

Interfaces / connectors2 × SFP28 (S-RF1/S-RF2); 2 × QSFP28 (Q-RF1/Q-RF2)

Power supplytypical consumption 136 W at 25 °C (ETSI ES202 706)

Additional technical information

Installation environment: Field-replaceable capacity board inside the chassis AirScale
Dimensions: 25 × 219 × 364 mm (H × W × D)
Weight: 2.1 kg (unpacked)
IP rating: IP20
Bandwidth: Supported 5G-configurations SRAN20A: 5/10/15/20 MHz 2T2R/4T4R; 100 MHz 32T32R
Architecture: Field-replaceable board AirScale SM: cellular processing baseband and optical fronthaul to radio modules
Subtype: Capacity plug-in unit
Details: Operating temperature: front-to-back airflow — −5…+55 °C; back-to-front — −5…+50 °C
Installation conditions: B-subrack slot AirScale
Connection notes: Radio units via fronthaul; common board via backplane
