RBS 6401 B1

Name: Ericsson RBS 6401 B1
Brand: Ericsson

What it does: Integrated pico base station

2 part numbers: KRD 901 039/1 / KRD901039/1

Viewing: model overview

Request a Quote

Request current availability, condition and pricing. Delivery terms are agreed in the quotation.

Additional technical information

IP rating: PN KRD901039/1; IP21
For PN KRD901039/1.
Power supply: PN KRD901039/1; 100–250 V AC; manufacturer platform 50/60 Hz; Brazilian certificate states 60 Hz, 2 A
For PN KRD901039/1.
Family: PN KRD901039 / 1; RBS 6401
For PN KRD901039 / 1.
Dimensions: PN KRD901039/1; 409 × 258 × 91 mm
For PN KRD901039/1.
Weight: PN KRD901039/1; 5 kg
For PN KRD901039/1.
Installation environment: PN KRD901039/1; Indoor IP21; wall, ceiling or shelf mounting; 0 to +50 °C; Brazilian certificate excludes residential use
For PN KRD901039/1.
Interfaces / connectors: PN KRD901039/1; SFP facility; optical/electrical Ethernet connections; optional external cellular-antenna connection
For PN KRD901039/1.
Interfaces and data rates: PN KRD901039/1; Optical/electrical Ethernet via SFP; optional bonded-copper transmission; GPS/NTP/1588v2/SyncE/NTR timing interfaces
For PN KRD901039/1.
Technologies: PN KRD901039/1; WCDMA/HSPA; RBS 6401 platform also supports LTE FDD; no Wi-Fi board in /1
For PN KRD901039/1.
Operating RF bands / ranges: PN KRD901039/1; B1
For PN KRD901039/1.
Downlink frequency: PN KRD901039/1; 2110–2165 MHz (Brazil-certified HSPA transmitter range)
For PN KRD901039/1.
RF output power: PN KRD901039/1; Up to 2 × 1 W manufacturer platform rating; 0.8531 W maximum in the Brazilian HSPA certification
For PN KRD901039/1.
Bandwidth: PN KRD901039/1; RF IBW 25 MHz; LTE carrier up to 20 MHz or two WCDMA carriers
For PN KRD901039/1.
Capacity: PN KRD901039/1; Up to 64 WCDMA or 128 LTE active users; up to two WCDMA carriers
For PN KRD901039/1.
Synchronization: PN KRD901039/1; GPS, NTP, IEEE 1588v2, Synchronous Ethernet and NTR
For PN KRD901039/1.
Chassis: PN KRD901039/1; Compact indoor IP21 enclosure with integrated antenna; wall, ceiling or shelf mounting
For PN KRD901039/1.
Modules: PN KRD901039/1; Integrated cellular radio/baseband, antenna, AC power and GPS; SFP and optional transmission-module facilities; Wi-Fi board absent in /1
For PN KRD901039/1.
Functional role: PN KRD901039/1; Indoor pico/femtocell radio base station
For PN KRD901039/1.
Architecture: PN KRD901039/1; Single compact integrated RBS with cellular radio/baseband, antenna, AC supply and synchronization functions
For PN KRD901039/1.
Subtype: PN KRD901039/1; Integrated multi-standard WCDMA/LTE small cell, no Wi-Fi board in /1
For PN KRD901039/1.
Details: PN KRD901039/1; Exact /1 variant has no Wi-Fi board; integrated GPS with external-antenna option; supports integrated/optional Ethernet transmission alternatives
For PN KRD901039/1.
Installation conditions: Wall; ceiling; shelf
